Q-WiFi-Fone

Airello Q-WiFi-Fone

Phone with VoIP and WLAN

Q-WiFi-Fone provides
     an effective, reliable
          mobile telephone communication system
               for indoors and outdoors applications

Ideal for use in Corporate Offices, Restaurants,
Warehouses, Hospitals and Car Dealerships

Q-WiFi-Fone wireless IP phone enhances productivity and allows greater mobility in the workplace.

Q-WiFi-Fone operates over intelligent IP network infrastructure with IEEE802.11b compliant wireless access points and allows the phone users to place calls across the existing data network with SIP protocol.

Features and Specifications

Signaling

SIP (RFC3261)
SDP (RFC2327)
CODEC: G.711u/aLaw, G.729a/b, G.723.1a (optional)
DTMF detection and relay
Acoustic Echo Cancellation
Silence Suppression
Voice Activity Detection (VAD)
Comfort Noise Generation (CNG)

Wireless

IEEE 802.11b support
Frequency band: 2.400 - 2.497 GHz
Channel: FCC Ch1.11, ETSI Ch1.13, Japan Ch1.14
Data Rate: 11/5.5/2/1 Mbps
Sensitivity: -82dBm @ 11 Mbps
Operating Range: Outdoor up to 300 m, Indoor up to 75 m
Site Survey: Scan available access points in handset's environment
Support infrastructure (public) mode and Ad-hoc mode (option)
Compatible to most major access point manufacturer

Network

IP address assignment: Fixed IP, DHCP client, PPPoE
IPv6/IPv4, HTTP, TFTP, TCP, UDP, DNS, ARP, ICMP
Tag VLAN support
QoS support TOS/DiffServ
NAT Traversal
Direct IP-to-IP call

Management

LCD screen displayed menu and keypad settings
Built-in Web Configuration
Support Auto-Configuration
Direct Management using USB cable

Call Features

Similar in operation to a cell-phone
Make second call (first call on hold)
Switch between first and second calls
Transfer call
Call waiting
Call Return and Redial
Call Forward
Push-to-Talk
Presence Awareness with SIMPLE

Applications

Call Log
Phonebook
Network Game (Optional)

Security & Encryption

WEP, WPA-PSK security
64/128 bit WEP encryption, AES, TKIP

Certification Compliance

VCCI Class B
ISO 9000

Hardware

Dimensions (H x W x D): 131 mm x 47 mm x 11 mm
Weight: 90 g
Battery Capacity: 3.5 hours talk, 40 hours standby
Display: 30 mm x 30 mm GUI LCD with 128x128, Backlight
Buttons: 12 standard dialing keys (0-9, *, #) with characters, 4 soft keys, and 4 directional navigation + push stick key, Button-Lock key, Send/End/Clear keys
Notification Ringer, Vibration
Supported Ports: Headset or Earphone jack, USB port

Interface

Multilingual English, Japanese, Korean
Display GUI for ease-of-use

Accessories

Power Adaptor AC 110 - 240 V, Output DC 5 V
Battery Pack Additional
USB cable Optional
Headset Optional
Carrying case Optional

Reliability

Operating Temperature: 0 - 40 C
Storage Temperature: -10 - 60 C
Humidity: 20% - 80% (Non-Condensing)
